Electrocardiograph TELECARDIO

TeleCardio is a 12-lead, fully diagnostic electrocardiograph which displays, acquires, prints and stores ECG tracings, for adults and children, together with its measurements. Using color touchscreen display all operations can be easily performed. All information (ECG, interpretation, HRV graphs, etc.) can be printed out.

Features
  • ECG channels
  • Dimensions (mm)
  • Weight (kg)
  • Automatic ECG interpretation
  • Paper
  • ECG-record length (sec)
  • Operating
  • Storage for ECG records
  • Power supply
  • Leads systems
  • Accuracy of measurement of signal amplitude, intervals and durations

  • 12
  • 217*220*59
  • 1.2
  • by Minnesota Code
  • 112mm
  • 4, 8, 10
  • touchscreen and keyboard
  • up to 100
  • battery or mains
  • Standard, Neb, Kabrera, Frank, Slapak (optional)
  • EN 60601-2-25
  • Simultaneous recording of 12 ECG leads
  • LCD for ECG view
  • Operating via touchscreen
  • 5' printer
  • Built-in GPRS modem
  • Updating using PC
  • Rhythm recording with automatic arrythmia detection
  • Electrode break detection
  • Possibility of headset connection
  • ECG signal transmitting by GSM
  • ECG report receiving to the screen
